| Studio Movieboard Pci Capture Hardware |
|
 Larger image
|
List Price: $126.27
Our Price: $74.99
You Save: $ 51.28 (41%)
Availability: Usually ships in 24 hours
Manufacturer: Pinnacle
|
Average Customer Rating:
|
|
Binding: CD-ROM
Brand: Pinnacle Systems
EAN: 0613570219965
Feature: Package Contents - Pinnacle Studio Software install DVD / Pinnacle Studio / Pinnacle InstantDVD Recorder / Pinnacle MediaManager / Pinnacle Studio Bonus DVD / Pinnacle Studio User Guide / 500-PCI Internal Video Capture Card
Format: CD-ROM
Is Autographed: 0
Is Memorabilia: 0
Label: Pinnacle
Manufacturer: Pinnacle
Model: 230100110
Platform: No Operating System
Publisher: Pinnacle
Studio: Pinnacle
|
|
|
Features
|
Package Contents - Pinnacle Studio Software install DVD / Pinnacle Studio / Pinnacle InstantDVD Recorder / Pinnacle MediaManager / Pinnacle Studio Bonus DVD / Pinnacle Studio User Guide / 500-PCI Internal Video Capture Card
Inputs & Outputs - Composite video input/output (RCA connector) PAL,SECAM (input only), NTSC / S-Video input/output (mini-DIN connector) PAL,SECAM (input only), NTSC / IEEE 1394 In/Out connector (6-pin type)
Analog Video Capture to Computer - Video format - NTSC/PAL/SECAM (SECAM input only) Frame rate PAL - 25 frames per second/50 fields per second / Frame rate NTSC - 30 frames per second/60 fields per second / Frame size PAL - 720x576 / Frame size NTSC - 768x480 / Compression - MPEG-2, MPEG-1, DV, MJPEG
Video Playback from Computer - Analog PAL/NTSC output / DV (IEEE 1394) output to camcorder 25 Mbit/s.
Import Formats - Video - DV, AVI MPEG-1, MPEG-2, DivX,MPEG-4, 3GP(MPEG-4), WMV, Non-encrypted DVD titles Audio - WAV, MP3 / Graphic - BMP, JPG, PCT, TGA, TIF, WMF / Export Formats Video CD (VCD) or S-VCD with optional CD burner / DVD with optional DVD burner (DVD-R, DVD-RW,DVD+R or DVD+RW) DV, AVI, DivX, RealVideo 8, Windows Media 9,MPEG-1, MPEG-2, MPEG-4 files / Apple iPod and Sony PSP compatible (MPEG-4) formats / Dolby Digital 2 channel & 5.1 channel audio
|
|
|
|
|
|
|
|
|
Editorial Reviews:
|
Preserving and enhancing your old home movies and new digital video is easier than ever with this all-in-one hardware and software combination from Pinnacle, the worldwide leader in home video editing.Pinnacle Studio MovieBoard is the versatile movie making solution for people who want to make great home movies without limitation, offering flexible video capture capabilities with comprehensive video editing tools. The internal PCI card captures video from any analog or digital source to make great movies from existing VHS tapes or new DV camcorders with plug and play ease.
|
|
|
| Spotlight customer reviews: |
|
Customer Rating:
Summary: Works well. Not a high-end card, though.
Comment: When I first opened the box and looked at the details, there were two things that concerned me right away:
1) The card does not capture audio. It requires that the audio signal is routed through your sound card.
2) The card lists several capture formats, but it's important to note that the various formats are available via *software*. i.e., it appears that the card itself just captures frames, and it's the Pinnacle Studio software that does the conversion into DV/MPEG/etc. in real-time.
However, even with those two limitations I did a 2-hour capture from an old VHS tape (albeit via a Time Base Corrector box) and the whole capture went flawlessly. Not a single dropped frame, and no out-of-sync audio (the most common problems one might have with such a capture setup).
I have/had a Hauppauge PVR-250, Pinnacle DC10+, Pinnacle AV/DV, and various capture capabilities integrated into video cards. This card fits into the middle of the lot. It doesn't have the integrated audio capture or hardware compression capabilities of the PVR-250 or the AV/DV, but it works well, and the flexibility of capture formats (albeit via software) is nice to have.
Customer Rating:
Summary: Very Happy
Comment: Purchased two of these boards to capture video through the PC. Software that came with the board was current. Easy installation. Opened capture software and had camera image. Worked great! Price was the lowest I found on the web and shipping was on-time.
Customer Rating:
Summary: Works as Advertised
Comment: I think this is a great kit for the price. The card and software installed with no major issues, and the analog video capture from my old camcorder works great. Captures in AVI or MPEG, and the editing software is pretty cool. You'll want to upgrade 1GB of memory. I only have 512MB and it starts swapping during editing.
Otherwise, I highly recommend this product.
|
|
|
|
|
|
|
|
|
|
|
|
|
